Nanocrystalline toroidal core 59×52×5 mm
59×52×5 mm nanocrystalline toroidal core, Blue colored Powder Coating.
CCNT-059-052-005-STBL is a 59×52×5 mm nanocrystalline toroidal core with Blue powder coating.
In stock
$20.881 piece
Choose a pack, set quantity up to 49 of this pack (49 pieces), then add to cart. When the cart has items, use the cart icon in the header to review them and keep shopping before checkout.
Loading checkout…
Volume pricing
Online packs are $10.00 minimum. Buy packs totaling under 50 pieces. 50+ is quoted.
| Pack / qty | Unit price | How to buy |
|---|---|---|
| 1 piece | $20.88 | Buy online |
| Pack of 3 | $19.84 | Buy online |
| Pack of 5 | $18.79 | Buy online |
| Pack of 10 | $16.70 | Buy online |
| 50+ pieces | Quoted | Request quote |
Technical Specifications
Bare core dimensions
Cased / finished dimensions
Magnetic properties
Finish and handling
Environmental
Product photos
Applications and selection
Recommended usage
- small current transformers
- pulse transformers
- signal isolation
DIY & R&D usage
- DIY current-transformer winding
- small pulse transformer experiments
Technical applications
- low-current sensing transformers
- pulse transformers
- signal isolation cores
When to choose this size
Choose CCNT-059-052-005-STBL when you need this 59×52×5 mm toroidal core. Use the bare dimensions for the magnetic path and the finished dimensions, when published, for winding clearance.
Winding notes
Magnetic calculations should use the bare 59×52×5 mm geometry. AL, Ae, and Le were not measured for this core. Saturation is 1.25 T.
Related application guides
Frequently asked questions
Are the stated dimensions bare or finished?
The size in the product name is the bare core. Finished dimensions are listed separately when they were measured.
Where is a core this size used?
This 59×52×5 mm powder-coated toroid is a large-window, low-height core for current sensing, pulse transformers, and signal isolation. The 51 mm finished opening and 5 mm stack suit a cable used as a single-turn primary, or a flat pulse transformer where the part must stay short.
What finish is on this core?
This core is finished with Blue powder coating.
Need this core for your application?
Get pricing, availability, and winding support for CCNT-059-052-005-STBL.
